Operation precautions and installation of Chinese medicine grinder

1. Check whether there is any foreign matter in the crushing chamber (it must be empty before turning on), and turn on the power.
2. Tighten the butterfly nut of the upper cover and the crushing chamber.
3. Start the motor, run the machine empty for 1-2 minutes, and then gradually feed the hit material from the feed tray. The feed should not be too fast or too much.
4. If the material is stuck and the motor does not rotate, please turn it off immediately to prevent the motor from burning. After the stuck material is removed, you can continue to use it.
5. It is strictly forbidden to open the upper cover and reach into the crushing cavity by hand during the use of this machine.
6. This machine is a dry type crusher, which is not suitable for crushing damp and greasy materials.
7. The user is requested to replace different screens according to their needs.
8. This machine adopts overheat protector, if the motor load is too heavy, it will stop automatically. If you continue to operate, please press the protector again.
9. During the working process of this machine, the current shall not exceed 15 amperes.

Chinese medicine grinder installation
1. The machine should be installed in a place that is relatively flat and convenient to use.
2. Before work, the materials to be processed must be selected cleanly, and hard materials such as metal objects and stones are not allowed to be mixed into the machine to avoid damage to the internal parts or failure of the machine.
3. Before starting the machine, check whether the parts are firm and reliable. Everything is normal before it can work.
4. Turn on the power supply, run idling for 1-2 minutes, check whether the operation is normal, and only after everything is normal, can feed. When the machine is working, the operator cannot leave. Once the sound is abnormal, the power supply should be cut off immediately. When processing raw materials, the outlet should be fastened with a longer cloth bag.
5. When the machine is in use, if the power supply voltage is too low, do not use it to avoid damage to the motor. When the power supply voltage is normal, the machine is not easy to be damaged, and the production efficiency is still high. During the trial operation of the hammer mill, the machine body vibrated fiercely. The important reasons and treatment methods are as follows:
(1) The hammer device is wrong during maintenance and disassembly. When the hammers are used in reverse and U-turn, in order to prevent the rotor components from being balanced, all the hammers in the crusher must be re-turned and turned, otherwise there will be intense vibration during operation.
(2) The difference in the weight of the corresponding two sets of hammers exceeds 5 grams. The cleaning method is to adjust the weight of the hammer so that the difference between the corresponding two sets of components is less than 5 grams.
(3) Generally, the hammer is stuck too tightly and is not thrown away during operation. After stopping the machine, you can turn it by hand to observe, and think of ways to make the hammer rotate sensitively.
(4) The components of other parts on the rotor are not balanced. At this time, it is necessary to discern and carefully check the adjustment balance.
(5) The main shaft is bent and deformed. The processing method is straightening or changing.
(6) The clearance of the bearing (provided product: ball bearing) exceeds the limit or is damaged. Ordinarily, the issue is dealt with by replacing the new bearing.
(7) The bottom corner fixing nut is not tightly fixed or loosened during operation. The treatment method is tightening.
